Zhejiang Xinna Medical Device Technology Co., Ltd.

1.2 micron IV Filter for infusion therapy

Dettagli:
Luogo di origine: Cina
Marca: OEM avaliable
Certificazione: YY 0286.1 GB 8368-2018 ISO9001
Numero di modello: F33
Termini di pagamento e spedizione:
Quantità di ordine minimo: 100,000pcs
Prezzo: $0.15-$0.22 per piece
Imballaggi particolari: 750 pezzi per confezione con etichetta, 4 confezioni per cartone o personalizzabili
Tempi di consegna: 30 giorni
Termini di pagamento: L/C, T/T
  • Informazioni dettagliate
  • Descrizione di prodotto

Informazioni dettagliate

Nome del prodotto: Filtro IV usa e getta da 1,2 micron Custodia di filtro: ABS
Dimensione dei pori: 1.2um Materiale medio: PES, PTFE per le prese d'aria
Ferma altezza liquido: ≥ 1,5 metri Modo dell'Assemblea: Fusione termica o saldatura ad ultrasuoni
Sterilizzazione: Non sterili/EOS Tipo: F, monouso
Vantaggi: Fermo liquido automatico Colore: Naturale, a prova di luce disponibile
Compatibilità: Compatibile con tubi IV standard Garanzia: 3 anni
Applicazione: Set per infusione Paese di origine: Cina
Evidenziare:

1.2 micron

,

iv filter 1.2μm

,

infusion set

Descrizione di prodotto

IV Filter With Hydrophilic PES-pp 1.2μm and Hydrophobic PTFE 0.45μm for infusion set



F33 IV Filter is an air eliminating filter for the removal of inadvertent particulate debris and other components like incomplete mixing of drugs and entrained air in catheter which may be found in solutions intended for intravenous use. The filtration efficiency of the membrane and the overall design of the filter can impact the safety of drug delivery for human beings.



Features :

  • Easy to connect to IV tubing sets with standard luer inlet and outlet slip
  • Precision filtration of fine particles
  • High retention efficiency
  • Range of pore size options
  • Automatic air-stop
  • Lightproof-colored housings for light sensitive drugs is available
  • Printing available for ease of product identification

Specifications:





Dimensions: 57*29.5*0.94mm(inlet/outlet connector included)
Weight: 5.7-5.8g
Filtration area: 6.0CM2
Venting area: 0.54CM2
Venting air flow rate: 25ml/min@5kpa
Max burst pressure: 3.6bar(52.5psi)
Operating Temp: 5-40℃
Storage Temp: 0-50℃
Filtration rate: PES-PP 5.0μm ≥95%,
PES-PP 3.0/2.0/1.2μm ≥90%
Min water flow rate: PES-PP 1.2μm ≥500ml/10min@10kpa
PES-PP 2μm ≥600ml/10min@10kpa
PES-PP 3μm ≥800ml/10min@10kpa
PES-PP 5μm ≥1000ml/10min@10kpa
Sterilization: Ethlene Oxide(Max 60℃)



Applications:

  • Filter is designed for use in filtration of intravenous for removal of particles larger than 1.2μm
  • Infusion set



Package&Label:



3000pcs/box, 4 inner PE bags with 750 pcs inside each. each bag is sealed separately and cushion between each other.
Each bag is labeled with information as following, different lots in one box are closed separately and labeled seperately to prevent.
